Alloy Steel Seamless Pipe ASTM A335 ASME SA335 P5 P9 P11 P12 P22 P91 P92 Power Plant Energy Fluid System Boiler Thermal Power

Produktdetails:

Herkunftsort:	China
Markenname:	YUHONG GROUP
Zertifizierung:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Modellnummer:	SA335 P5 P9 P11 P12 P22 P91 P92

Zahlung und Versand AGB:

Min Bestellmenge:	500 kg
Preis:	Verhandelbar
Verpackung Informationen:	Standard-Exportpaket
Lieferzeit:	10-15 Tage
Zahlungsbedingungen:	L/C, T/T
Versorgungsmaterial-Fähigkeit:	10000 T pro Monat

Kontakt

Alle Produkte

Nahtlose Rohre aus Edelstahl (342)

Edelstahl-nahtloses Rohr (335)

Duplexedelstahl-Rohr (134)

Duplexedelstahl-Rohr (39)

Nadelröhre (170)

Flossenröhrchen (733)

Wärmetauscher (35)

Wärmetauscherrohr (472)

Wärmetauscher-Rohrbund (52)

Wärmetauscher-Rohrboden (128)

Wärmetauscherleitblech (39)

Luftkühler (14)

Druckbehälter (4)

Edelstahl geschweißtes Rohr (61)

Edelstahl geschweißtes Rohr (134)

Nickel-Legierungs-Rohr (276)

Nickel-Legierungs-Rohr (104)

Kupferlegierungs-Rohr (257)

Legierter Stahl-Rohr (217)

Titanrohr (21)

helles getempertes Rohr (174)

Rauchrohr (155)

Stahlinstallation (874)

Stahlflansch (671)

Andere (409)

Teile für Verkleidungen (9)

Ausführliche Produkt-Beschreibung

Standard:	Die in Anhang I der Richtlinie 2008/57/EG genannten Anforderungen gelten für die Berechnung der in A	Material:	P5 P9 P11 P12 P22 P91
Verarbeitung:	Biegen, Schweißen, Abwickeln, Stanzen, Schneiden	Länge:	Einzelne zufällige Länge/Doppelzufällige Länge
Anwendung:	Flüssigkeitsrohr, Kesselrohr, Bohrrohr, Hydraulikrohr, Ölrohr	Paket:	Eisenrahmenboxen

Alloy Steel Seamless Pipe ASTM A335 ASME SA335 P5 P9 P11 P12 P22 P91 P92 Power Plant Energy Fluid System Boiler Thermal Power

YUHONG GROUP deal with alloy steel seamless pipe and tube already more than 32 years, every year sell more than 80000 tons of alloy steel seamless pipe and tube. Our client already cover more than 65 countries. Our alloy steel seamless pipe and tube was width used in Mining, Energy, Petrochemical, Chemical Industry, Food plant, Paper plant, Gas and Fluid Industry etc. ANSI B16.10: B16.19 SCH 5S, SCH 10S, SCH 20, SCH 30, SCH 40S, SCH 60, SCH80S, XS, SCH 100, SCH 120, SCH160, XXS

Alloy Steel Seamless Pipe ASTM A 335 Specification :

Seamless ferritic Alloy-Steel Pipe for high temperature service. Pipe ordered to this specification shall be suitable for bending, flanging (vanstoning), and similar forming operations, and for fusion welding. Sometimes referred to as "P Grade”, chome moly pipe is popular in P-Grades P5, P9, P11, P22, and P91. The most common use of grades P11, P22, and P91 is in the power industry and petro-chemical plants, Grades P5 and P9 are commonly used in refineries

Alloy Steel Seamless Pipe ASTM A 335 P5 Chemical Composition:

Compositions	Data
UNS Designa-tion	K41545
Carbon(max.)	0.15
Manganese	0.30-0.60
Phosphorus(max.)	0.025
Silicon(max.)	0.50
Chromium	4.00-6.00
Molybdenum	0.45-0.65
Other Elements	…

Alloy Steel Seamless Pipe ASTM A 335 P5 Mechanical Properties :

Properties	Data
Tensile strength, min, (MPa)	415 Mpa
Yield strength, min, (MPa)	205 Mpa
Elongation, min, (%), L/T	30/20

Alloy Steel Seamless Pipe ASTM A 335 P5 Heat Treatment :

	P5, P9, P11 and P22
Grade	Heat Treatment Type	Normalizing Temperature Range F [C]	Subcritical Annealing or Tempering Temperature Range F [C]
P5 (b,c)	Full or isothermal Anneal
	Normalize and Temper	*****	1250 [675]
	Subcritical Anneal (P5c only)	*****	1325 - 1375 [715 - 745]
P9	Full or isothermal Anneal
	Normalize and Temper	*****	1250 [675]
P11	Full or isothermal Anneal
	Normalize and Temper	*****	1200 [650]
P22	Full or isothermal Anneal
	Normalize and Temper	*****	1250 [675]
P91	Normalize and Temper	1900-1975 [1040 - 1080]	1350-1470 [730 - 800]
	Quench and Temper	1900-1975 [1040 - 1080]	1350-1470 [730 - 800]
