ASME SB163 N02201 Nickel Alloy Seamless Condensers And Heat Exchangers Tubes

ASME SB163 N02201 Nickel Alloy Seamless Condensers And Heat Exchangers Tubes

  • ASME SB163 N02201 Nickel Alloy Seamless Condensers And Heat Exchangers Tubes
  • ASME SB163 N02201 Nickel Alloy Seamless Condensers And Heat Exchangers Tubes
  • ASME SB163 N02201 Nickel Alloy Seamless Condensers And Heat Exchangers Tubes
  • ASME SB163 N02201 Nickel Alloy Seamless Condensers And Heat Exchangers Tubes
ASME SB163 N02201 Nickel Alloy Seamless Condensers And Heat Exchangers Tubes
Produktdetails:
Herkunftsort: China
Markenname: YUHONG
Zertifizierung: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Modellnummer: ASME SB163
Zahlung und Versand AGB:
Min Bestellmenge: 500 kg
Preis: Depend
Verpackung Informationen: PLY-Woodden-Fall
Lieferzeit: 30 bis 65 Tage
Zahlungsbedingungen: T/T, L/C
Versorgungsmaterial-Fähigkeit: 1000 tons/Monat
Kontakt
Alle Produkte
Nahtlose Rohre aus Edelstahl (290)
Edelstahl-nahtloses Rohr (277)
Duplexedelstahl-Rohr (127)
Duplexedelstahl-Rohr (29)
Nadelröhre (107)
Flossenröhrchen (631)
Wärmetauscher (17)
Wärmetauscherrohr (424)
Wärmetauscher-Rohrbund (37)
Wärmetauscher-Rohrboden (116)
Wärmetauscherleitblech (36)
Luftkühler (8)
Druckbehälter (4)
Edelstahl geschweißtes Rohr (57)
Edelstahl geschweißtes Rohr (114)
Nickel-Legierungs-Rohr (261)
Nickel-Legierungs-Rohr (79)
Kupferlegierungs-Rohr (227)
Legierter Stahl-Rohr (184)
Titanrohr (10)
helles getempertes Rohr (153)
Rauchrohr (145)
Stahlinstallation (804)
Stahlflansch (590)
Andere (391)
Teile für Verkleidungen (7)
Ausführliche Produkt-Beschreibung
Produkt: Kondensatoren und Wärmetauscherrohre Rohrmaterial für Kondensatoren und Wärmetauscher: Nickellegierung
Kondensatoren und Wärmetauscherrohre Standard: ASME SB163 Kondensator- und Wärmetauscherrohrqualität: N02201
Anwendung für Kondensatoren und Wärmetauscherrohre: Wärmetauscher/Kessel/Kondensatoren usw. Verpackung von Kondensatoren und Wärmetauscherrohren: PLY-Woodden-Fall
Hervorheben:

ASME SB163 nickel alloy tubes

,

N02201 seamless condenser tubes

,

nickel alloy heat exchanger tubes

ASME SB163 N02201 Nickel Alloy Seamless Condensers And Heat Exchangers Tubes

YUHONG Group can offer ASTM B163 / ASME SB163 N02201 SMLS nickel alloy tubes.



ASTM B163 / ASME SB163 is the standard specification for seamless nickel and nickel-alloy condenser and heat-exchanger tubes. N02201 (Alloy 201) likes N02200, it's a commercially pure nickel (99.0% min) known for its excellent resistance to corrosion, particularly in caustic environments, and its high thermal and electrical conductivity. Its seamless nature ensures reliability under pressure and in corrosive service.N02201 resists corrosion in a wide range of reducing and neutral media, including fresh water, natural waters, non-oxidizing salts, and alkaline solutions. It is particularly resistant to caustic alkalies.


N02201 maintains good strength and ductility from cryogenic temperatures up to moderately high temperatures. Alloy 201 has very low carbon content (<0.02%), which prevents carbide precipitation (sensitization) during welding and service, preserving its corrosion resistance in the heat-affected zones.



ASME SB163 N02201 Nickel Alloy Seamless Condensers And Heat Exchangers Tubes 0



Chemical Composition % Alloy 201 / UNS N02201


Nickel Copper Iron Manganese Carbon Silicon Sulfur
99.0 min 0.25 max 0.40 max 0.35 0.02max 0.35 0.01
Nickel element shall be determined arithmetically by difference.


Mechanical Property Alloy 201 / UNS N02201


Condition Tensile Strength min Yield Strength min Elongation (%) Rockwell Hardness
Annealed  50ksi (345MPa) 28ksi (193MPa) 40 min. /
  Stress-relieved 60ksi (414MPa) 55ksi (379MPa) 15 min. B62 max



SB163 N02201 tubes common applications include:



Caustic Evaporators and Concentrators
Tubes are used in heat exchangers that concentrate sodium hydroxide (NaOH) or potassium hydroxide (KOH) solutions from weak concentrations to 50% or even 73%. Stainless steel would corrode catastrophically in this service.
Chemical Processing Industry (CPI)
1.Organic Chlorination Processes: Handling chlorinated hydrocarbons and associated by-products like HCl.
2.Production of Plastics and Synthetic Fibers: Where corrosive catalysts or intermediates are present.
3.Fine Chemical and Pharmaceutical Synthesis: For reactors and heat exchangers handling aggressive media where purity is critical (nickel ions are less problematic than corrosion products from other metals).
Power Generation & Marine
1.Feedwater Heaters in Advanced Plants: Where water chemistry is highly controlled, and reliability is paramount.
2.Specialized Condensers: In geothermal plants or in coastal/offshore facilities where cooling water is highly aggressive, brackish, or polluted, and where chlorination is used for biofouling control.

Other Specialized Applications
1.HF Alkylation Units in oil refineries (for handling hydrogen fluoride).
2.Production and Handling of Fluorine and Fluorinated Compounds.
3.Sea Water Desalination Plants, particularly in the high-temperature brine heaters and sections with high chloride concentration.



Testing and Inspection



Hydrostatic Test (or Nondestructive Electric Test)

Flattening Test,Reverse Flattening Test

Flaring Test

Hardness Test

Tension Tests

Chemical Analysis


ASME SB163 N02201 Nickel Alloy Seamless Condensers And Heat Exchangers Tubes 1
