ASTM B423 UNS N08825 Incoloy 825 Nickel Alloy Steel Seamless Large Diameter Tube, Resistant To High Temperature, High Concentration Acid

ASTM B423 UNS N08825 Incoloy 825 Nickel Alloy Steel Seamless Large Diameter Tube, Resistant To High Temperature, High Concentration Acid

  • ASTM B423 UNS N08825 Incoloy 825 Nickel Alloy Steel Seamless Large Diameter Tube, Resistant To High Temperature, High Concentration Acid
  • ASTM B423 UNS N08825 Incoloy 825 Nickel Alloy Steel Seamless Large Diameter Tube, Resistant To High Temperature, High Concentration Acid
  • ASTM B423 UNS N08825 Incoloy 825 Nickel Alloy Steel Seamless Large Diameter Tube, Resistant To High Temperature, High Concentration Acid
  • ASTM B423 UNS N08825 Incoloy 825 Nickel Alloy Steel Seamless Large Diameter Tube, Resistant To High Temperature, High Concentration Acid
ASTM B423 UNS N08825 Incoloy 825 Nickel Alloy Steel Seamless Large Diameter Tube, Resistant To High Temperature, High Concentration Acid
Produktdetails:
Herkunftsort: China
Markenname: YUHONG
Zertifizierung: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Modellnummer: Astm b423 uns n08825
Zahlung und Versand AGB:
Min Bestellmenge: 100 kg
Preis: Verhandelbar
Verpackung Informationen: Sperrholzgehäuse/Eisengehäuse/Bündel mit Kunststoffkappe
Lieferzeit: 20-80 Tage
Zahlungsbedingungen: L/C, T/T
Kontakt
Alle Produkte
Nahtlose Rohre aus Edelstahl (327)
Edelstahl-nahtloses Rohr (322)
Duplexedelstahl-Rohr (134)
Duplexedelstahl-Rohr (36)
Nadelröhre (152)
Flossenröhrchen (698)
Wärmetauscher (24)
Wärmetauscherrohr (456)
Wärmetauscher-Rohrbund (46)
Wärmetauscher-Rohrboden (124)
Wärmetauscherleitblech (39)
Luftkühler (10)
Druckbehälter (4)
Edelstahl geschweißtes Rohr (61)
Edelstahl geschweißtes Rohr (130)
Nickel-Legierungs-Rohr (271)
Nickel-Legierungs-Rohr (96)
Kupferlegierungs-Rohr (247)
Legierter Stahl-Rohr (208)
Titanrohr (20)
helles getempertes Rohr (173)
Rauchrohr (151)
Stahlinstallation (855)
Stahlflansch (655)
Andere (404)
Teile für Verkleidungen (8)
Ausführliche Produkt-Beschreibung
Standard: ASTM B423 Spezifikation: UNS N08825 Incoloy 825
Form: Runden Typ: Nahtlos
Länge: Maßgeschneidert Bearbeitungsservice: Biegen, Schweißen, Abwickeln, Stanzen, Schneiden
Hervorheben:

ASTM B423 Incoloy 825 nickel alloy tube

,

UNS N08825 seamless large diameter pipe

,

high temperature acid resistant nickel alloy tube

ASTM B423 UNS N08825 Incoloy 825 Nickel Alloy Steel Seamless Large Diameter Tube, Resistant To High Temperature, High Concentration Acid



ASTM B423 UNS N08825 tube is a seamless tube made of a nickel-iron-chromium-based austenitic alloy. Tubes manufactured according to this standard are widely used in petrochemical, marine engineering, and nuclear power industries.

The commercial grade is Incoloy 825. It is a nickel-based alloy specifically designed for extremely corrosive environments, exhibiting excellent resistance to stress corrosion cracking by sulfuric acid, phosphoric acid, and chloride ions, and performing exceptionally well in high-temperature, high-concentration acid, and chloride-containing media.



Chemical Composition (Ladle Analysis)
Element Composition (wt%)
Nickel (Ni) 38.0 – 46.0
Iron (Fe) ≥ 22.0 (balance)
Chromium (Cr) 19.5 – 23.5
Molybdenum (Mo) 2.5 – 3.5
Copper (Cu) 1.5 – 3.0
Titanium (Ti) 0.6 – 1.2
Carbon (C) ≤ 0.05
Manganese (Mn) ≤ 1.00
Silicon (Si) ≤ 0.50
Phosphorus (P) ≤ 0.030
Sulfur (S) ≤ 0.030





Mechanical Properties (Seamless Pipe, Solution Annealed)
Property Cold Finished Hot Finished Requirement Min.
Tensile Strength, min 586 MPa (85 ksi) 517 MPa (75 ksi) 586 MPa (85 ksi)
Yield Strength (0.2% offset), min 241 MPa (35 ksi) 172 MPa (25 ksi) 241 MPa (35 ksi)
Elongation (in 2 in / 50 mm), min 30% 30% 30%
Hardness (Rockwell B), max 90 HRB 90 HRB 90 HRB





Physical Properties (Typical Values)
Property Value
Density 8.14 g/cm³ (0.294 lb/in³)
Melting Range 1370 – 1400 °C (2500 – 2550 °F)
Specific Heat Capacity (20 °C) 440 J/(kg·K) (0.105 Btu/(lb·°F))
Thermal Conductivity (20 °C) 10.8 – 11.0 W/(m·K) (75 Btu·in/(ft²·h·°F))
Electrical Resistivity (20 °C) 112 – 113 μΩ·cm
Modulus of Elasticity (20 °C) 195 GPa (28.3 × 10³ ksi)
Modulus of Rigidity (20 °C) 76 GPa (11.0 × 10³ ksi)



Application

  • Petrochemicals: Residue hydrogenation unit pipelines, sour gas pipelines, offshore platform oil and gas transportation
  • Chemical processing: Sulfuric acid/phosphoric acid production equipment, acid washing heating pipes, reactor pipelines
  • Marine engineering: Seawater cooling heat exchangers, seawater desalination plants, subsea pipelines
  • Nuclear power: Nuclear fuel reprocessing equipment; Resistant to various corrosive media combinations
  • Oil and gas extraction: Downhole control pipelines, chemical injection pipelines, sour gas well equipment



ASTM B423 UNS N08825 Incoloy 825 Nickel Alloy Steel Seamless Large Diameter Tube, Resistant To High Temperature, High Concentration Acid 0
