ASTM A790 S32205 Seamless Duplex Stainless Steel Tube High Strength Corrosion Resistant for Offshore Applications

ASTM A790 S32205 Seamless Duplex Stainless Steel Tube High Strength Corrosion Resistant for Offshore Applications

  • ASTM A790 S32205 Seamless Duplex Stainless Steel Tube High Strength Corrosion Resistant for Offshore Applications
  • ASTM A790 S32205 Seamless Duplex Stainless Steel Tube High Strength Corrosion Resistant for Offshore Applications
  • ASTM A790 S32205 Seamless Duplex Stainless Steel Tube High Strength Corrosion Resistant for Offshore Applications
  • ASTM A790 S32205 Seamless Duplex Stainless Steel Tube High Strength Corrosion Resistant for Offshore Applications
ASTM A790 S32205 Seamless Duplex Stainless Steel Tube High Strength Corrosion Resistant for Offshore Applications
Produktdetails:
Herkunftsort: CHINA
Markenname: YUHONG
Zertifizierung: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Modellnummer: ASTM A790 UNS S32750
Zahlung und Versand AGB:
Min Bestellmenge: 500 kg
Preis: Verhandelbar
Verpackung Informationen: Sperrholzkoffer /Eisenfall
Lieferzeit: 15-30 Tage
Zahlungsbedingungen: L/c, t/t
Versorgungsmaterial-Fähigkeit: 1500 Tonnen pro Monat
Kontakt
Alle Produkte
Nahtlose Rohre aus Edelstahl (290)
Edelstahl-nahtloses Rohr (277)
Duplexedelstahl-Rohr (127)
Duplexedelstahl-Rohr (29)
Nadelröhre (107)
Flossenröhrchen (631)
Wärmetauscher (17)
Wärmetauscherrohr (424)
Wärmetauscher-Rohrbund (37)
Wärmetauscher-Rohrboden (116)
Wärmetauscherleitblech (36)
Luftkühler (8)
Druckbehälter (4)
Edelstahl geschweißtes Rohr (57)
Edelstahl geschweißtes Rohr (114)
Nickel-Legierungs-Rohr (261)
Nickel-Legierungs-Rohr (79)
Kupferlegierungs-Rohr (227)
Legierter Stahl-Rohr (184)
Titanrohr (10)
helles getempertes Rohr (153)
Rauchrohr (145)
Stahlinstallation (804)
Stahlflansch (590)
Andere (391)
Teile für Verkleidungen (7)
Ausführliche Produkt-Beschreibung
Standard: ASTM A790 Grad: UNS S32205
Materialtyp: Duplex aus Edelstahl Größenbereich: Angepasst
Oberflächenbeschaffung: mit einem Gehalt an Rohstoffen von mehr als 85 GHT Anwendung: Offshore -Anwendungen
Hervorheben:

ASTM A790 S32205 seamless duplex tube

,

high strength corrosion resistant steel tube

,

offshore duplex stainless steel tube

ASTM A790 S32205 Seamless Duplex Stainless Steel Tube High Strength Corrosion Resistant for Offshore Applications



YUHONG GROUP​​ is a specialized manufacturer of ​​high-performance duplex stainless steel products, with over 30 years of expertise in serving global energy and chemical industries. Our ​​ASTM A790 S32205 Seamless Duplex Stainless Steel Tubes​​ combine superior corrosion resistance with exceptional mechanical strength for the most demanding applications.

Heat Treatment Requirements for UNS S32205



Parameter​​ ​​Requirement​​
​​UNS Designation​​ S32205
​​Type​​ 2205
​​Temperature Range​​ 1870–2010 °F [1020–1100 °C]
​​Quenching Method​​ Rapid cooling in water or by other means

​Chemical Composition of UNS S32205



Element​​ ​​Requirement (%)​​ ​​Notes​​
​​Carbon (C)​​ ≤0.030 Controls carbide formation
​​Manganese (Mn)​​ ≤2.00 Improves hot workability
​​Phosphorus (P)​​ ≤0.030 Minimizes brittleness
​​Sulfur (S)​​ ≤0.030 Enhances machinability
​​Silicon (Si)​​ ≤1.00 Deoxidizer and strength enhancer
​​Nickel (Ni)​​ 4.5-6.5 Austenite stabilizer
​​Chromium (Cr)​​ 22.0-23.0 Primary corrosion resistance
​​Molybdenum (Mo)​​ 3.0-3.5 Pitting resistance enhancer
​​Nitrogen (N)​​ 0.14-0.20 Strength and corrosion resistance

Tensile and Hardness Requirements for UNS S32205



Property​​ ​​Requirement​​ ​​Unit​​
​​UNS Designation​​ S32205 -
​​Type​​ 2205 -
​​Tensile Strength, min​​ 95 [655] ksi [MPa]
​​Yield Strength, min​​ 65 [450] ksi [MPa]
​​Elongation in 2 in. or 50 mm, min​​ 25 %
​​Hardness, max (HBW)​​ 290 HBW
​​Hardness, max (HRC)​​ 30 HRC

​​ASTM A790 S32205 Seamless Duplex Stainless Steel Tube - Key Application Advantages​



1. Superior Mechanical Strength for Offshore Structures​​

​​Minimum yield strength 450 MPa (65 ksi)​​ withstands extreme ocean wave loads and high-pressure drilling operations

​​25% minimum elongation​​ provides critical ductility to absorb dynamic stresses in subsea pipelines

​​2. Unmatched Corrosion Resistance in Marine Environments​​

​​PREN ≥ 35​​ (Cr+3.3Mo+16N formula) prevents pitting/crevice corrosion in chloride-rich seawater

​​Resists stress corrosion cracking (SCC)​​ under tension in the splash zone and submerged conditions

​​3. Long-Term Reliability in Critical Applications​​

​​50+ year service life​​ in North Sea oil platforms (documented cases)

​​Maintenance cost reduction​​ up to 60% compared to 316L systems through eliminated cathodic protection needs

​​4. Operational Safety Enhancements​​

​​Inherent fire resistance​​ maintains structural integrity at high temperatures (PED compliance)

​​Zero toxicity leaching​​ ensures compatibility with seawater cooling for LNG processing

ASTM A790 S32205 Seamless Duplex Stainless Steel Tube High Strength Corrosion Resistant for Offshore Applications 0
